機械一覧




奥野機械はフラットリングマシン、ウェーブスプリング成形機、コイリングマシンやフォーミングマシン、その他ばね機械及び様々な線材加工機械を幅広いラインナップでご用意しています。
ご要望に応じて最適な機械をご提案致します。

※製品に合わせて必要な機能やオプションなどの組み合わせが非常に多いため、詳細は営業担当者までお問合せください。




▶CM・CML : メカ式コイリングマシン
メカニカルな構造のコイルばねの成形機です。スイッチばね、弁ばね、クラッチばね等の成形に適しています。D/d=2のバネの加工が可能です。
As the name implies, mechanical coiling machines form springs through a mechanical process.They are mostly used to produce springs for switches, valves, clutches, and other applications.They can produce prings with an inner-outer diameter ratio down to D/d=2.
▶CM-CNC : C-Zコイルフォーマー
従来のメカ式コイリングマシンからカム及びワンウェイクラッチを取除き、各スライドの動き及び線送りを数値制御化する事により、コイリング機能とフォーミング機能を合わせ持ったコイルフォーマーです。多種少量生産、高付加価値スプリングの製作及びセットアップ時間の短縮を目的とした機械です。
All slide and wire feeding of this machine is computerised on the basis of mechanical coilingmachine for having coiling and forming both functions. Purpose of this machine is these, making high value spring, making small quantity spring, shortening set-up time.
▶MCF : マルチコイルフォーマー
コンピューターによる数値制御方式で、各スライド及び線送りを制御する為、専用金型・カム等の必要がなく、曲げR&曲げ角度の変更が容易に出来ます。線送りに関しての制限がありません。又、他の機械 との連動も可能です。
Special metal mold and cam are unnecessary on this machine because all slide and wire feeding are controlled by computer. Sample making or angle modification, etc. will be much easier. Other machines can be connected on.
▶CF(TF) : コイルフォーミングマシン
ACサーボモーターを採用し、より複雑な加工を可能にする為にコイル成形機と多方向スライド成形機を組み合わせました。最大8軸まで軸数の追加が可能です。
CF type machine is the coil former combined with multi slide forming machine for the pupose of making complicated spring. Additional servo controlled axis available (Max..8 axes total).
▶RM : リングメーキングマシン
丸線より1巻もしくは2巻のリングを製作するのに適した機械です。RM-S型は線送り構造に、数値制御を取り入れた新世代型の機械です。
This machine is suitable for making 1 or 2 tuen ring by round wire. NC wire feed system is adoptedon RM-S type machine. It's new generation.
▶RMF : フラットリングメーキングマシン
異形線リングに成形機です。止め輪(スナップリング)、ウェーブリング、ウェーブばね、ピストンリング等の成形に適しています。真円形状ではなく変形したリンゴ形状や楕円形状のリングの形成も可能です。
These machines can from snap rings, wave rings, wave springs, piston rings and other types of spring foms which must be made from shaped wire. They produce not only round forms, but also elli ptical and free form rings .
▶RMF-200CNC : 溶接リング成形ライン
本ライン機は異形線材をリング加工・溶接加工・バリ取り加工及び焼とん処理の工程を
トランスファー装置により搬送する自動ライン機です。
▶TFV : 縦型トーションフォーミングマシン
縦型の軸巻き式コイル成形機で、足部の曲げ加工等の複雑加工を可能にする為、スピンドル軸、ピッチ軸、線送り軸、カム軸にACアダプターを採用し、数値制御を行っています。ニクロム線コイルやタングステン発光コイル、銅線ブレーカーコイル等の成形に適しています。
These are vertical type torsion spring formers that use CNC control. They also use precision AC servo motors for spindle, pitch, wire feed, and cam drive in order to produce complex sping configurations. These machines are best for producing spring products made from nickel chrome wire coils, luminous tungsten coils, or copper wire circuit breaker coils.
▶FM : フォーミングマシン
線バネ、薄板バネ、溶接バネ、組合わせ加工等を行うのに優れた多方向スライド加工式プレス機です。コイリングマシンと同様OKUNO独自の機構を多数装備しています。
These are multi-slide press forming machines which can produce small wire springs, leaf springs, brazing rings and other springs and wire foms. The FM forming machines are also capable of parts assembly. Basic spring forms which can be made by the FM spring formers.
▶OCF : オーバルコイルフォーマー
本機は楕円バネ成形機の専用機です。1点専用のツールを使用すれば超高速生産が可能です。ツール調整とデータ調整で多角型バネの高速生産も可能です。ノンストップ成型方式(PAT.)が可能な成形機です。
These are specialized machines used to form oval coils. They can produce coils non-stop at super-highproduction speeds when equipped with our patented tooling. Polygon coils can also be produced at high speeds with special tools and control data programming.
▶MSC・MSW : ゼンマイ成形機
MCF-15型機及びMSW-15型機は長尺物のゼンマイを成形するのに適した機械です。箱詰めや組立までの自動ライン化、外周保持用のワイヤーリングを製作しながら挿入すること等可能です。シートベルトやコードリールぜんまいの成形に適した機械です。
Our MCS and MSW machines were developed to form motor springs used in seat belt , cord retractor, and other similar mechanisms. They can even form a retainer ring around the motor spring as part of theprocess. These machines can be packaging or assembly operations.

▶特殊成形機
当社のコイリングマシン、フォーミングマシンの製造技術を応用した特殊形品製造用の機械です。
There machines are designed OKUNO’s technical experiences of Coiling Machine & Forming Machine.
●ジグザグ成形機
●フレキシブルチューブ製造機
●スパイラル成形機
●医療用機器
その他 クサリ製造機、自転車サドルバネ成形機、セパレータ製造機、シャッターバネ製造機
超大径バネ成形機、電柱鉄筋製造機、特殊トーションバネ自動組立機


▶オプション
お客様のご要望に沿えるように、さまざまなオプション装置をご用意しております。その内の一部をご紹介いたします。これら以外にもいろいろなオプション装置がございますので、遠慮なくお問合せください。
We prepare various option devices to be able to comply with the demand of the users. We introduce a part of those,please refer to us without hesitation.
●包装装置:テーピング包装、パレット包装、袋詰め包装
●矯正器
●プレス装置(油圧式)
●搬送装置
●自動線台:細線用、キャリヤ用線台、OT線用線台 ボビン用線台
▶金型
各種機械の標準ツールです。製作をしています。 特殊ツールについても製作可能ですのでお問合せください。


▶全自動システムライン
●CSマスター CSMASTER
●弁ばね製造ライン VALVE SPRING MANUFACTURING LINE
●リトラクターぜんまい成形ライン RETRACTOR SPRING FORMING LINE
●トーションコイル成形ライン TORSION COIL FORMING LINE
●ブラジャーリング成形ライン BRASSIERERING FORMING LINE
